SpecificationEN 61131-2, type 1/3Number of channels8 inputs + 8 outputsNominal voltage24 V DC (-15%/+20%)“0” signal voltage-3…+5 V (EN 61131-2, type 1/3)“1” signal voltage11…30 V (EN 61131-2, type 3)Input currenttyp. 3 mA (EN 61131-2, type 3)Input filtertyp. 3.0 msDistributed clocks–Load typeohmic, inductive, lamp loadMax. output current0.5 A (per channel)Reverse voltage protectionyesBreaking energy< 150 mJ/channelSwitching timestyp. TON: 60 µs, typ. TOFF: 300 µsAuxiliary power currentno dataCurrent consumption E-bustyp. 90 mAElectrical isolation500 V (E-bus/field potential)Special featurescombi module, 8 x output 24 V DC, max. output current 0.5 A, load type: ohmic, inductive, lamp load, reverse voltage protectionWeightapprox. 30 gOperating/storage temperature-25…+60°C/-40…+85°CRelative humidity95%, no condensationEMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27Protect. rating/installation pos.IP20/see documentationApprovals/markingsCE, UL
