Connection technologypulse train (frequency output)Power supplyvia the E-busNumber of outputs1 channel (2 outputs A, B)Capture/compare input/output1/2Input specification24 V DCOutput specification5…24 V DC, external supplyLoad typeohmic, inductiveDistributed clocksyesMax. output current1 AShort-circuit current–Base frequency0…500 kHz, 50 kHz defaultResolutionmax. 15 bit (16 bit + sign)Current consumption E-bustyp. 135 mAElectrical isolation500 V (E-bus/field potential)Special featuresdifferent modes, ramp function, travel distance controlWeightapprox. 30 gOperating/storage temperature0…+55°C/-25…+85°CRelative humidity95%, no condensationEMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27Protect. rating/installation pos.IP20/see documentationApprovals/markingsCE, UL
