Power supply24 V (-15%/+20%)Number of outputs2 channel A/B, 1 channel A/B/C (4 differential outputs)Input specification–Output specificationRS422, differential, 50 mA, min. 120 Ω loadLoad typeohmic, min. 220 ΩDistributed clocksyesMax. output currentRS422 specification, 50 mAShort-circuit currentshort-circuit proofBase frequency0…4 MHz, 50 kHz defaultResolution16 bit (incl. sign, scaled via the set frequency range)Step sizemin. 10 ns (internal)Auxiliary power currenttyp. 50 mA (load dependent)Current consumption E-bustyp. 180 mAElectrical isolation500 V (E-bus/field potential)Special featuresABC incremental encoder simulation with connection to TwinCAT NCWeightapprox. 50 gOperating/storage temperature0…+55°C/-25…+85°CRelative humidity95%, no condensationEMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27Protect. rating/installation pos.IP20/see documentationApprovals/markingsCE
